Features

• Special controller for sequencer software (optimized for Ableton Live)
• Setup files for Ableton Live as of version 4.1 are shipped with the controller


  Take the Live internal control surface ‘LV2_LX2_LC2_LD2’ to have all controls automapped.
  (setting files no longer necessary)


• Independent of operating system and computer type (PC or Mac) due to the midi interface
  (no driver necessary)
• 6 track faders - switchable between 2 fader groups (1-6, 7-12)
• 4 push-encoders for jump-free control of track-dependent and track-independent parameters
  (total of 144 parameters)
• Main function for fast encoder access to important functions like trackselect, slot/scene-scroll, mastervolume, clip/scene-launch etc.
• Joystick to control track-dependent and track-independent parameters (total of 30 parameters)
• 2 button rows with each 6 buttons and LED’s, programmable independent in 6 keymodes
  (scene-launch, fx-control, mute, solo etc.)
• Parameter feedback of LIVE button statuses is indicated by LED’s (Mute, FX)
• Fadermute for all controls by holding down the instrument's SHIFT button
• Faderposition view by LED’s if holding down the instrument's SHIFT button
• Play-LED to show the beat speed
• Independent power supply by standard or rechargeable batteries 3 x AA cell,
  lifetime about 30 to 60 hours
• Powersave mode after 10 minutes of the last movement (running light)
• LED battery control
• Socket for an external power adaptor (4.5-6V DC - min. 50 mA)
• Midi-merge function
• Very compact design in a black, plastic casing (desktop format 180x105x70 mm, 450 g)
• Silver aluminium front plate with anodised coating (abrasion resistant) and inscriptions
• 51 LED's in different colors to display various information (low basic lights of all LED's
  for better orientation in dark club atmosphere)
• High-quality faders, encoders and joystick from ALPS
• Expandable system by other micromodul controllers (easy chaining by midi connections)
• Compatible to the 1st/2nd micromodul line (same cc/note numbers like LV1, LX1, LX2, LC2, LD2)

System requirements

• PC or Mac with a free USB port (1.0 or higher) or any USB hub
• Ableton Live (as of version 4.1) or software which allows user assignments of continuous parameters (CC) and note commands


Downloads

• Manual (PDF)
• Bedienungsanleitung (PDF)
• Ableton Live setup file (ALS) for Ableton Live version 4.1 or higher


      discontinued / ask for remain devices
